Pilot Hole Size Calculator

A wood screw needs the right holes or it fights you. Too small a pilot in hardwood and the screw splits the board or snaps off; no clearance hole and the two boards never pull tight. This gives you the pilot, the clearance hole and the countersink for any screw gauge, in hard or soft wood.

Three holes, three jobs

The pilot hole is for the board the screw threads into. It is a touch smaller than the screw's root so the threads cut and grip without wedging the wood apart. The clearance hole, in the top board, matches the screw's outer diameter so the screw slips through and the head pulls that board down onto the other. The countersink lets a flat head sit flush.

Why hardwood gets a bigger pilot

Dense woods like oak and maple have little give, so a tight pilot builds huge pressure as the threads cut, and the board splits or the screw twists off. A slightly larger pilot in hardwood relieves that without giving up grip. Softwood is forgiving, so a smaller pilot there lets the threads bite deeper. That is why the two columns differ.

The clearance hole makes the joint tight

Skip the clearance hole and the screw threads grab the top board as much as the bottom, so the two never cinch together and a gap stays. Drill the top board to the screw's shank diameter and the threads pass through it freely, pulling it down hard onto the piece below. This one step is the difference between a loose joint and a tight one.

When sources disagree

Pilot charts vary by a drill size from one book to the next, because wood, screw and how much grip you want all move the number. Treat this as a solid starting point. If the screw drives hard or the wood creaks, back out and go one size larger; if it spins without biting, go smaller. A scrap test in the actual wood settles it.
